Details:
- 1 Inch Quad Stainless Ratchet Buckle Tie-Down Assembly, ATL Part KS199-SS (Rev H), CRW1S-3M Wide Handle Ratchet Buckles Sewn To CHO4S-10M 4 Inch O Ring, CHS1S-3M Stainless S Hook On Each Strap
- CRW1S-3M Stainless Steel Ratchet With Wide Handle
- Fixed End 2.58 Ft (31 Inches)
- Adjustable Strap 9.5 Ft
- Total Strap Length 12.08 Ft (145 Inches)
- CWUS1-B3N 1 Inch 3M Blue Flat Nylon Webbing
- 7200 lb Break Strength
- 2,400 lb Working Load Limit
- Assembled in the USA
Product Weight: 9.05 lb
$206.59 Each
10+ = $188.18
50+ = $169.82
This product is a special order item and cannot be ordered online. Please contact Customer Service for assistance.
PRODUCT ASSEMBLY:
PRODUCT NOTES:
SPECIAL WARNINGS:
- Tie-downs, 4 Point Tie-down, S Hook On Each End
- 4 Point Ratchet Tie-down Configuration, O-ring In Middle, Ratchet With S Hook On The End Of All Four Straps
- Each Of The Four Straps Is An Individual Ratchet Strap Made Up Of A Fixed End And An Adjustable Strap
- The Fixed End Strap Is Sewn To The O-ring
- The Adjustable Is Sewn Through The Ratchet Spindle With A Pull Loop Sewn-in So The Adjustable Strap Cant Be Removed
- Heavy Duty Ratchet For The Highest Strength And Durability
- Ratchets Are Made Of 304 Grade Stainless Steel
- Ratchet Has The Standard Single Locking Configuration
- Ratchet Has A Wide Handle That Makes Operation Easier While Wearing Gloves
- Heavy Duty S Hook For The Highest Strength And Durability
- S Hooks Are Made From 304 Grade Stainless Steel
- S Hook Is The Standard Configuration With One Closed Eye End And An Open Hook End. The Hook End Has A Hook Opening Diameter Of Greater Than 1 Inch Which Allows The Hook To Fit A 1 Inch Diameter Bar Such As A Handlebar
- Strap Is Made With 3800 Lb Flat Nylon Webbing
- Sewn With Silver Polyester Thread
- Fixed End Strap Length Is Measured As The Webbing Only. Adjustable Strap Is Measured From The Front Of The Buckle To The Tip Of The Hook, Pull Loop Is Not Included
- Strap Is Double Stitched On The Fixed End And On The Hook End Of The Adjustable Strap. Pull Loop Is Single Stitched.
- CustomTieDowns Strap Warning Label Sewn On The Hook End Of An Adjustable Strap
- Single Unit Polybag Packaging With Label
| Model | Component | Break Strength | WLL |
|---|---|---|---|
| CWUS1-B3N | 1 Inch 3M Blue Flat Nylon Webbing | 3,800 lb | 1,267 lb |
| CHO4S-10M | 4 Inch 10M Stainless Steel Forged O-Ring, 316 SS | 10,000 lb | 3,333 lb |
| CHS1S-3M | 3M Stainless Steel S Hook | 3,000 lb | 1,000 lb |
| CRW1S-3M | Stainless Steel Ratchet With Wide Handle | 3,300 lb | 1,100 lb |
-
There are no special warnings for this product. Please see our Safety Warnings page for standard product warnings.
