Complete your order
Pricing & ordering
Choose your quantity and add this customized configuration to your cart.
$4.99 Each
10+ = $4.50
50+ = $4.06
Product at a glance
Details & specifications
Break strength
2500 lb
Working load limit
833 lb
1 Inch Strap
Components & materials
- 5 Inch Flat Sewn Loop on One End, CHD1-3M D-Ring on Opposite end
- CW1-Y3PE 1 Inch 3M Yellow Polyester Tie-Down Webbing
Dimensions
- Product weight: 0.14 lb
- Total Strap Length 2 Ft (24 Inches)
Product notes
- Tie-downs, Strap Extender, Flat Sewn Loop On One End, D-ring On The Opposite End
- Strap Extender Configuration, Strap Only, Sewn To A Specific Length, Has No Tightening Mechanism
- 5 Inch Flat Loop Sewn On The End Of The Strap Is Formed By Folding The Webbing Flat On Top Of Itself, No Pinching, Narrowing Or Twisting Of The Webbing
- 5 Inch Flat Loop Has A 10 Inch Circumference And Can Fit Over A 3 Inch Inch Diameter Round Bar
- D-ring On The Opposite End Provides An Anchoring Connection Point
- Heavy Duty D-ring For The Highest Strength And Durability
- Wire D-ring Is Made Of Steel And Has A Zinc-yellow Plated Finish For Superior Weather Protection
- Strap Is Made With 3000 Lb Polyester Tie-down Webbing
- Sewn With Silver Polyester Thread
- Strap Length Is Measured From The Tip Of The Sewn Loop To The Inside Edge Of The D-ring
- Sewn In The Standard Method To Meet Provided Strength Rating
- CTD Strap Warning Tag Sewn On The D-ring End Of The Strap
Component specifications
Component strengths
Safety information
Special warnings
- If Winding This Strap In A Boat Winch, Check That The Combination Of Strap Length And Webbing Thickness Will Fit In The Boat Winch When Wound Up
Additional views
Product images
Compare your options
Available Product Variations
There are no additional product variations currently available.
For help finding another option, contact customer service at sales@customtiedowns.com or 1-877-360-5528.
