Complete your order
Pricing & ordering
Choose your quantity and add this customized configuration to your cart.
$21.79 Each
10+ = $19.75
50+ = $17.83
Product at a glance
Details & specifications
Break strength
5000 lb
Working load limit
1,667 lb
1-3/4 Inch Strap
Components & materials
- CHS1K-5M black resin s Hook, hook opening facing down, on One End
- CW175-Y6PE 1.75 Inch Yellow Polyester Tie-Down Webbing
Dimensions
- Product weight: 1.06 lb
- Total Strap Length 6 Ft (72 Inches)
Product notes
- Tie-downs, Replacement Strap, S Hook On One End
- Replacement Strap Configuration, S Hook On One End, Opposite End Is Loose
- Replacement Strap Only, Product Does Not Include The Fixed End Or A Buckle
- S Hook Is The Heavy Duty Version For The Highest Strength And Durability
- S Hook Is Made Of Steel Wire And Has A Black Resin Finish
- S Hook Is The Standard S Hook Configuration, One Closed End, One Open Hook End. The Open Hook End Has A Diameter Larger Than 1.25 Inch To Fit Over A 1.25 Inch Diameter Bar Such As A Handlebar
- Strap Is Made With 6000 Lb Polyester Tie-down Webbing
- Sewn With White Polyester Thread
- Strap Length Is Measured As The Webbing Only And Does Not Include The Length Of The Hook
- Sewn In The Standard Method To Meet The Provided Strength Rating
- CustomTieDowns Strap Warning Tag Sewn On The Hook End Of The Strap
Component specifications
Component strengths
| Model | Component | Break Strength | WLL |
|---|---|---|---|
| CW175-Y6PE | 1.75 Inch Yellow Polyester Tie-Down Webbing | 6,000 lb | 2,000 lb |
| CHS1K-5M | 5M S Hook, Black Resin Finish | 5,500 lb | 1,833 lb |
Safety information
Special warnings
There are no special warnings for this product. Please see our Safety Warnings page for standard product warnings.
Additional views
Product images
Compare your options
Available Product Variations
There are no additional product variations currently available.
For help finding another option, contact customer service at sales@customtiedowns.com or 1-877-360-5528.
